MCL100 Metal Detector

The MCL100 Metal Detector is a rugged, budget-friendly non-motion locator engineered for utility contractors and ground engineering teams. Featuring an extendable aluminium shaft, built-in loudspeaker, and straightforward dual-dial controls, it delivers reliable depth location for buried metallic assets.

Non-Motion Target Tuning: Employs a simplified dual-knob coarse and fine adjustment framework to lock in an accurate audio threshold without complex digital programming.
High-Visibility Field Chassis: Assembled with a rugged, high-contrast casing and matching search head to ensure maximum tool visibility and operator safety near moving traffic.
Telescopic Aluminium Stem: Designed with a fully adjustable extendable shaft mechanism to accommodate variable operator heights and compact storage configurations.
Traffic-Isolation Audio Path: Fitted with a built-in loudspeaker alongside a dedicated 3.5mm headphone socket to cut out heavy background site noises during precision sweeps.

ADD TO YOUR QUOTE

Enquire about hiring or buying this product. You’ll be contacted by one of our Sales Team.

Adding one of these to your enquiry?

Kolectric MC8022 Covermeter

Laserliner ThermoCamera Connect

Laserliner VideoFlex HD Borescope

Full Description

The MCL100 Metal Detector is a durable, field-proven non-motion locator specifically developed for the utility, construction, and street works sectors. Designed for high efficiency without complex menus, this detector is optimised to pinpoint lost or buried ferrous and non-ferrous metallic targets, such as manhole covers, valve boxes, stopcock casings, and marker plates. Its distinctive high-visibility chassis ensures excellent safety awareness on busy highway workspaces, serving as an indispensable tool for rapid pre-excavation checks. The streamlined control console is engineered with dual physical dials for coarse and fine tuning, allowing operators to establish an accurate audio threshold baseline in seconds. As the white search head passes over a hidden target, the internal speaker outputs a distinct, rising audio note relative to the object’s mass and depth. Built to endure harsh site conditions, the instrument features an adjustable telescopic aluminium stem for personalized ergonomics, an integrated headphone jack to counter deafening street traffic noise, and a low-draw circuit that extracts hours of continuous operation from a single standard battery cell.

FAQs

Does this model require a constant sweeping motion to signal a target?

No, it operates as a non-motion detector, meaning it will continue to output a steady, high-pitch note directly over a piece of metal even if you hold the search coil completely still.

Is the extendable shaft easy to lock into position?

The telescopic aluminium shaft features a smooth, robust collar lock that allows you to easily adjust and tighten the pole to match any operator’s preferred arm height.

What types of buried objects is this detector designed to find?

The MCL100 is optimised for commercial utility site use, making it ideal for locating lost manhole covers, metallic pipe joints, valve boxes, and deep pavement survey stakes.

Is the MCL100 Metal Detector available for hire?

Yes, this industrial metal detector is fully available within our extensive fleet for short-term and long-term hire, providing an economical rental option for clearing specific site footprints or recovering paved-over service covers.

How does the user tune the detector on site?

The device features a simple manual tuning system; using the coarse and fine adjustment knobs, you quickly roll the dial until the audio signal just drops out to set your peak sensitivity threshold.

How does the audio tone indicate different target depths?

The strength and volume of the audio response are depth-dependent, generating a sharp, loud signal for shallow components and a softer note for deeper structural assets.

Can this unit be used alongside standard cable avoidance tools?

Absolutely, this detector serves as a highly effective companion tool alongside your CAT and signal generator kits to clear ground spaces completely before digging.

Is there a way to mute the loudspeaker in noisy environments?

Yes, plugging standard headphones into the integrated top-panel socket automatically disconnects the external loudspeaker, helping you isolate subtle audio signals away from active machinery.

What power source does the MCL100 use?

The device runs efficiently on a single standard PP3 9V alkaline battery, which fits into a quick-access slide-out drawer located at the base of the main control console.

What is the best way to maintain the white search head?

Simply wipe down the lower search coil with a clean, damp cloth after working in thick mud or clay; avoid harsh chemicals or submersion of the top control box assembly.
